The BST-HPL-6200W Hybrid Solar Inverter is engineered for high-demand residential and small commercial installations. Featuring 48V battery compatibility and powerful MPPT technology, it ensures optimal solar performance and stable power output.

It supports large appliances including air conditioners, cookers, and water pumps while maintaining high efficiency and smart monitoring capability.

Key Features

·         48V battery system for improved efficiency & stability

·         High-power 100A MPPT charging controller

·         Pure sine wave output for heavy appliances

·         Supports air conditioners, pumps & refrigerators

·         Solar + Grid dual charging modes

·         Wide PV voltage range (60–500VDC)

·         Smart LCD display & monitoring

·         Intelligent cooling system

·         High surge capacity handling

·         Multi-layer safety protection system

Technical Specifications

• Model: BST-HPL-6200W
• Rated Power: 6200W
• Battery Voltage: 48VDC
• Output Voltage: 230VAC ±5%
• Waveform: Pure Sine Wave
• PV Voltage Range: 60–500VDC
• Max PV Voltage: 500VDC
• Max Charging Current: 100A
• AC Charging Current: 100A
• Efficiency (Peak): 98%
• Transfer Time: 10ms / 20ms
• Operating Temperature: 0°C – 55°C
• Dimensions: 495 × 312 × 125 mm
• Weight: 8.5 kg
