3.0KW/3.6KVA Hybrid Solar Inverter

The BST-HPL-3000W Hybrid Solar Inverter delivers powerful and stable performance for medium-sized residential and commercial solar systems. Designed with a high-efficiency MPPT controller, it maximizes solar energy utilization and ensures reliable battery charging.

With 24V battery compatibility and intelligent protection systems, this inverter is ideal for homes running refrigerators, TVs, lighting, pumps, and office equipment.

Key Features

·         Advanced MPPT solar controller for maximum energy harvest

·         Stable pure sine wave output

·         24V battery system design

·         Wide PV input voltage range (40–500VDC)

·         100A solar charging current

·         60A AC charging current

·         Seamless grid/solar switching

·         Intelligent battery charging (3-stage charging)

·         RS232 communication interface

·         Ideal for homes, offices & small businesses

Technical Specifications

• Model: BST-HPL-3000W
• Rated Power: 3000W
• Battery Voltage: 24VDC
• Output Voltage: 230VAC ±5%
• Waveform: Pure Sine Wave
• PV Voltage Range: 40–500VDC
• Max PV Voltage: 500VDC
• Max Charging Current: 100A
• AC Charging Current: 60A
• Efficiency (Peak): 98%
• Transfer Time: 10ms / 20ms
• Operating Temperature: 0°C – 55°C
• Dimensions: 399 × 285 × 118 mm
• Weight: 6 kg
